Structural Mechanics Apparatus

Structural Mechanics Apparatus

10 INR/Piece
Get a Price/Quote

Product Details:

  • Product Type Structural Mechanics Apparatus
  • Usage Applied Mechanics Lab Equipments
  • Application Applied Mechanics Lab Equipments
  • Click to view more
Request To Call Back Send Inquiry
X

Structural Mechanics Apparatus Price And Quantity

  • 1 Piece
  • 10 INR/Piece

Structural Mechanics Apparatus Product Specifications

  • Structural Mechanics Apparatus
  • Applied Mechanics Lab Equipments
  • Applied Mechanics Lab Equipments

Structural Mechanics Apparatus Trade Information

  • 100 Piece Per Month
  • 1 Week
  • No
  • Sample costs shipping and taxes has to be paid by the buyer
  • carton box, export quality also available
  • Middle East Africa Asia
  • All India
  • ISO 9001, 14001 ,CE

Product Description

Structural Mechanics Apparatus:

It is very easy to form different trusses with the given material and find out stress in different members.

The following fourteen types of models can be easily constructed :-

1. Single Cantilever
2. Single Cantilever with four members,
3. Simple Roof Truss
4. Roof Truss with Angled Tie Rods (Roof Truss 'A')
5.A Composite frame work (four in one frame)
6. King Post Roof Truss.
7. Standard Roof Truss (Roof Truss 'B')
8. Roof Truss With Loads or Standard Roof Truss.
9. Mansard Roof Truss.
10. Island Roof Truss.
11.N Type Girder
12.Warren Girder,
13. Framed Arch,
14. North Light Roof Truss

Details of Accessories :-

a. Stand and cross bars   (4 bars &8 stands)                             4 sets
b. Brackets fitted with stands.                                                4 only.
c. Hinges (different)                                                              22 only.
d. Hinge Holder Hooks.                                                           8 only.
e. Cantilever rod with top caps.                                               2 only.
f.  Member rods (sizes marked)                                                37 only.
g. Cap Screws (extra).                                                           6 only.
h. Weight hanger with platform.                                               8 only.
i. Weight platforms extra.                                                       2 only.
j. Slotted weights 1 kg.                                                          10 only.
k. Spring balances (2 of 20 kg. 2 of 10 kg.  (4 of 5kg.)                 8 only.
I.  Chains short and long.                                                        6 only.
m. Boss Brackets.                                                                  2 only.
