Electrical Teaching Equipment

Our Electrical Teaching Equipment range covers exclusively designed Transformer Trainer, Telephone Trainer Kit, Antenna Trainer Kit and more. These Electrical Teaching Equipment and products are specially designed to supplement electrical test kits required in engineering institutes and training centers for introducing students & learners to practical verification of operations related to telephone, antenna, transformer etc. All kits are thoughtfully designed, for instance, our antenna trainer kits are provided with a transmitter unit and a separate detector unit. Accompanying accessories are always supplied in convenient cases.

Product Image (MTK-512PRP)

TRANSISTOR CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS, REGULATED POWER SUPPLIES

Price: 10 INR/Piece

Transistor Characteristics Apparatus with Bakelite Panel & Round Meters, Regulated Power Supplies Objective: Input & Output Characteristics of Common Emitter PNP & NPN Transistors Input & Output Characteristics of Common Base PNP & NPN Transistor. Features: Instrument comprises of the following: Two DC Regulated Power Supplies 0-10VDC/150mA & 0-1VDC/150Ma Four round meters for voltage & current measurement with connections brought out at 4mm sockets One PNP & One NPN Transistor mounted behind the panel with connections brought out at 4mm sockets. Connections of Supplies & Transistors brought out at 4mm Sockets. Front Panel made of thick Bakelite sheet One ON/OFF Switch with jewel light is provided on the front panel. Made of Heavy duty metal box construction

Product Image (MTK-355FCR)

FET CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS

Price: 10 INR/Piece

FET Characteristics Apparatus with Bakelite Panel & Round Meters Two Variable DC Regulated Power Supply ( 0 - 5V & 0 - 15V ) Three Analog Moving Coil Meter ( 5V , 5 mA / 15 mA , 15V ) Power Requirement: 220V AC ±10%, 50Hz Cabinet Size (mm): 330 mm x 205 mm x 85 mm

Product Image (MTK-366TCD)

THERMISTOR CHARACTERISTICS APPARATUS WITH ALUMINUM PANEL & DIGITAL PANEL METERS

Price: 10 INR/Piece

Thermistor Characteristics Apparatus with Aluminum Panel & Digital Panel Meters Instruments Comprises DC regulated power supply 0-10 V dc / 150mA, two meters for voltage & current measurement one glass thermistor is kept in oven. Connections of supplies, meters & thermistor brought out at 4mm sockets. Also provided with oven with temperature control knobe.

Product Image (MTK-339PNS)

PN JUNCTION DIODE CHARACTERISTICS APPARATUS WITH ALUMINUM PANEL & SQUARE METERS

Price: 10 INR/Piece

PN Junction Diode Characteristics Apparatus with Aluminum Panel & Square Meters Instruments Comprises the two DC supply 0-1 V DC / 150mA & 0-50 V DC / 150mA, two dual range round meters for measurement of voltage & current PN Junction diode mounted behind the panel, connections of supplies, meters & diodes brought out at 4mm sockets.

Product Image (MTK-303ZDR)

ZENER DIODE V-I CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS (FORWARD & REVERSE)

Price: 10 INR/Piece

Zener Diode V-I Characteristics Apparatus with Bakelite Panel & Round Meters (Forward & Reverse) To study forward reverse V - I characteristics of zener diode. Complete Instrument with power supply, meters, zener diodes, connections of supplies.

Product Image (MTK-348PLD)

PN / ZENER DIODE / LED CHARACTERISTICS APPARATUS WITH ALUMINUM PANEL & DIGITAL PANEL

Price: 10 INR/Piece

PN / Zener Diode / LED Characteristics Apparatus with Aluminum Panel & Digital Panel Output voltage (Regulated) : 0-3V/30V DC ( Selectable) Meters (Analog): 65mm round 0-3V/30V DC (Dual Range), 0-100uA / 10mA DC (Dual Range). Housed in PVC cabinet, symbol diagram printed, connections of various components (PN Junction Diode 0A 79, Zener diode 5.1V, LEDs (Red, Green & Yellow), all important outputs & test points brought at Bakelite front panel.

Product Image (MTK-318SS)

SCR CHARACTERISTICS APPARATUS WITH ALUMINUM PANEL & SQUARE METERS

Price: 10 INR/Piece

SCR Characteristics Apparatus with Aluminum Panel & Square Meters It has an inbuilt variable DC-regulated power supply with an output voltage range of 0-30V DC. The setup includes on-board analog moving coil meters that can measure both voltage and current. The voltmeter has a dual range of 0-1.2V/0-30V, while the ammeter has a dual range of 0-200uA DC and 0-1.2mA/0-30mA.An SCR of 2P4M will be used for the experiment. The entire setup will be enclosed in a lightweight and shock-proof plastic cabinet.

Product Image (MTK-363SC)

SOLAR CELL CHARACTERISTICS APPARATUS

Price: 100 INR/Piece

Solar Cell Characteristics Apparatus Objective: To plot characteristics curve between voltage & current at different resistance of Solar Cell. Features: One Solar Cell mounted in a plastic box, light source, two analog meters mounted on front panels.

Product Image (MTK-331M)

TUNNEL DIODE CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & DIGITAL PANEL METERS

Price: 10 INR/Piece

Tunnel Diode Characteristics Apparatus with Bakelite Panel & Digital Panel Meters Inbuilt variable DC regulated power supply (0 -5VDC) On Board two Digital meters 4mm Banana Type Sockets on front panel Symbol diagram printed on Bakelite Front Panel Power Requirements: 230V AC ± 10%, 50Hz

Product Image (MTK-512PS)

TRANSISTOR CHARACTERISTICS APPARATUS WITH WITH ALUMINUM PANEL & SQUARE METERS, REGULATED POWER SUPPLIES

Price: 10 INR/Piece

Transistor Characteristics Apparatus with with Aluminum Panel & Square Meters, Regulated Power Supplies Objective: Input & Output Characteristics of Common Emitter PNP & NPN Transistors Input & Output Characteristics of Common Base PNP & NPN Transistor. Features: Instrument comprises of the following: Two DC Regulated Power Supplies 0-10VDC/150mA & 0-1VDC/150Ma Four round meters for voltage & current measurement with connections brought out at 4mm sockets One PNP & One NPN Transistor mounted behind the panel with connections brought out at 4mm sockets. Connections of Supplies & Transistors brought out at 4mm Sockets. Front Panel made of thick Bakelite sheet One ON/OFF Switch with jewel light is provided on the front panel. Made of Heavy duty metal box construction

Product Image (MTK-314ML)

MICROPHONE AND LOUDSPEAKER CHARACTERISTICS APPARATUS

Price: 10 INR/Piece

Microphone and Loudspeaker Characteristics Apparatus Meters: dB meter Range: 40-80dB, 80-120dB Housed in PVC cabinet, symbol diagram printed, 9V Power supply connected internally, Loudspeaker of 8.0 ohm. Capacitance Microphone, all important outputs & test points brought at Bakelite front panel.

Product Image (MTK-348PLS)

PN / ZENER DIODE / LED CHARACTERISTICS APPARATUS WITH ALUMINUM PANEL & SQUARE METER

Price: 10 INR/Piece

PN / Zener Diode / LED Characteristics Apparatus with Aluminum Panel & Square Meter Output voltage (Regulated) : 0-3V/30V DC ( Selectable) Meters (Analog): 65mm round 0-3V/30V DC (Dual Range), 0-100uA / 10mA DC (Dual Range). Housed in PVC cabinet, symbol diagram printed, connections of various components (PN Junction Diode 0A 79, Zener diode 5.1V, LEDs (Red, Green & Yellow), all important outputs & test points brought at Bakelite front panel.

Product Image (MTK-309VSR)

VOLTAGE STABILIZATION CHARACTERISTICS OF ZENER DIODE WITH BAKELITE PANEL & ROUND METER

Price: 10 INR/Piece

Voltage Stabilization Characteristics of Zener diode with Bakelite Panel & Round Meter To study Input Voltage, Output Voltage Char. & Output Voltage, Load Characteristics. Instrument consists of DC Power Supply, two round meters to measure input voltage & output voltage, one Zener Diode mounted on panel & connections brought out at terminals.

Product Image (MTK-541EGD)

ENERGY BAND GAP APPARATUS WITH ALUMINUM PANEL & DIGITAL PANEL METERS

Price: 10 INR/Piece

Energy Band Gap Apparatus with Aluminum Panel & Digital Panel Meters Inbuilt Variable DC Regulated Power Supply of 0-20V DC. Temperature Controlled Electric oven to heat up the Diode. Mercury thermometer is mounted on front panel to measure the temperature of oven Volt Meter Range of 20V DC for measure the Voltages. Current Meter Range of 500mA for measure the Current.

Product Image (MTK-366TCR)

THERMISTOR CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS

Price: 10 INR/Piece

Thermistor Characteristics Apparatus with Bakelite Panel & Round Meters Instruments Comprises DC regulated power supply 0-10 V dc / 150mA, two round meters for voltage & current measurement one glass thermistor is kept in oven. Connections of supplies, meters & thermistor brought out at 4mm sockets. Also provided with oven with temperature control knobe.

Product Image (MTK-541EGR)

ENERGY BAND GAP APPARATUS WITH BAKELITE PANEL & ROUND METERS

Price: 10 INR/Piece

Energy Band Gap Apparatus with Bakelite Panel & Round Meters Inbuilt Variable DC Regulated Power Supply of 0-20V DC. Temperature Controlled Electric oven to heat up the Diode. Mercury thermometer is mounted on front panel to measure the temperature of oven Volt Meter Range of 20V DC for measure the Voltages. Current Meter Range of 500mA for measure the Current.

Product Image (MTK-512PD)

TRANSISTOR CHARACTERISTICS APPARATUS WITH ALUMINUM PANEL & DIGITAL PANEL METERS, REGULATED POWER SUPPLIES

Price: 10 INR/Piece

Transistor Characteristics Apparatus with Aluminum Panel & Digital Panel Meters, Regulated Power Supplies Inbuilt Variable DC Regulated Power Supplies Output voltages : 0-1VDC, 0-10VDC On Board Digital Meters Voltmeter: 0-1VDC, 0-10VDC Ammeter: 0-50mADC, 0-250uA DC Transistors provided light weight shock proof plastic cabinet

Product Image (MTK-532FD)

WORK FUNCTION OF DIODE (RICHARDSON LAW)

Price: 10 INR/Piece

Work Function of Diode (Richardson Law) Objective: To draw the graphs between heater current vs heater resistance, Anode voltage vs anode current. Features: Instrument comprises of DC Regulated power supply of 0-6 V & 0-300 V. Two volt meters & two current meters are mounted on the front panel. Valve diagram is printed on the panel & connection are brought out on sockets/terminals.

Product Image (MTK-339PNR)

PN JUNCTION DIODE CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS

Price: 10 INR/Piece

PN Junction Diode Characteristics Apparatus with Bakelite Panel & Round Meters Instruments Comprises the two DC supply 0-1 V DC / 150mA & 0-50 V DC / 150mA, two dual range round meters for measurement of voltage & current PN Junction diode mounted behind the panel, connections of supplies, meters & diodes brought out at 4mm sockets.

Product Image (MTK-355FCS)

FET CHARACTERISTICS APPARATUS WITH ALUMINUM PANEL & SQUARE METERS

Price: 10 INR/Piece

FET Characteristics Apparatus with Aluminum Panel & Square Meters Two Variable DC Regulated Power Supply ( 0 - 5V & 0 - 15V ) Three Analog Moving Coil Meter ( 5V , 5 mA / 15 mA , 15V ) Power Requirement: 220V AC ±10%, 50Hz Cabinet Size (mm): 330 mm x 205 mm x 85 mm

Product Image (MTK-339PND)

PN JUNCTION DIODE CHARACTERISTICS APPARATUS WITH ALUMINUM PANEL & DIGITAL PANEL METERS

Price: 10 INR/Piece

PN Junction Diode Characteristics Apparatus with Aluminum Panel & Digital Panel Meters Instruments Comprises the two DC supply 0-1 V DC / 150mA & 0-50 V DC / 150mA, two dual range round meters for measurement of voltage & current PN Junction diode mounted behind the panel, connections of supplies, meters & diodes brought out at 4mm sockets.

Product Image (MTK-303ZDD)

ZENER DIODE V-I CHARACTERISTICS APPARATUS WITH ALUMINUM PANEL & DIGITAL PANEL METERS (FORWARD & REVERSE)

Price: 10 INR/Piece

Zener Diode V-I Characteristics Apparatus with Aluminum Panel & Digital Panel Meters (Forward & Reverse) To study forward reverse V - I characteristics of zener diode. Complete Instrument with power supply, meters, zener diodes, connections of supplies.

Product Image (MTK-355FCD)

FET CHARACTERISTICS APPARATUS WITH ALUMINUM PANEL & DIGITAL PANEL METERS

Price: 10 INR/Piece

FET Characteristics Apparatus with Aluminum Panel & Digital Panel Meters Two Variable DC Regulated Power Supply ( 0 - 5V & 0 - 15V ) Three Analog Moving Coil Meter ( 5V , 5 mA / 15 mA , 15V ) Power Requirement: 220V AC ±10%, 50Hz Cabinet Size (mm): 330 mm x 205 mm x 85 mm

Product Image (MTK-303ZDS)

ZENER DIODE V-I CHARACTERISTICS APPARATUS WITH ALUMINUM PANEL & SQUARE METERS (FORWARD & REVERSE)

Price: 10 INR/Piece

Zener Diode V-I Characteristics Apparatus with Aluminum Panel & Square Meters (Forward & Reverse) To study forward reverse V - I characteristics of zener diode. Complete Instrument with power supply, meters, zener diodes, connections of supplies.

Product Image (MTK-309PPC)

ENERGY BAND GAP BY FOUR PROBE METHOD WITH PC INTERFACE

Price: 10 INR/Piece

Energy Band Gap by Four Probe Method with PC Interface Digital Meters: Digital Milli Voltmeter 200mV / 2000mV Digital Milli Ammeter 20mA Power Supply: Constant Current Power Supply 20mA The experiment consists of the following: Four Probe Arrangement Oven: 200C

Product Image (MTK-318SD)

SCR CHARACTERISTICS APPARATUS WITH ALUMINUM PANEL & DIGITAL PANEL METERS

Price: 10 INR/Piece

SCR Characteristics Apparatus with Aluminum Panel & Digital Panel Meters It has an inbuilt variable DC-regulated power supply with an output voltage range of 0-30V DC. The setup includes on-board analog moving coil meters that can measure both voltage and current. The voltmeter has a dual range of 0-1.2V/0-30V, while the ammeter has a dual range of 0-200uA DC and 0-1.2mA/0-30mA.An SCR of 2P4M will be used for the experiment. The entire setup will be enclosed in a lightweight and shock-proof plastic cabinet.

Product Image (MTK-541EGS)

ENERGY BAND GAP APPARATUS WITH ALUMINUM PANEL & SQUARE METERS

Price: 10 INR/Piece

Energy Band Gap Apparatus with Aluminum Panel & Square Meters Inbuilt Variable DC Regulated Power Supply of 0-20V DC. Temperature Controlled Electric oven to heat up the Diode. Mercury thermometer is mounted on front panel to measure the temperature of oven Volt Meter Range of 20V DC for measure the Voltages. Current Meter Range of 500mA for measure the Current.

Product Image (MTK-309VSD)

VOLTAGE STABILIZATION CHARACTERISTICS OF ZENER DIODE WITH ALUMINUM PANEL & DIGITAL PANEL METERS

Price: 10 INR/Piece

Voltage Stabilization Characteristics of Zener diode with Aluminum Panel & Digital Panel Meters To study Input Voltage, Output Voltage Char. & Output Voltage, Load Characteristics. Instrument consists of DC Power Supply, two round meters to measure input voltage & output voltage, one Zener Diode mounted on panel & connections brought out at terminals.

Product Image (MTK-339PNS)

BOLTZMAN CONSTANT APPARATUS WITH PN JUNCTION DIODE WITH ALUMINUM PANEL & DIGITAL PANEL METERS

Price: 10 INR/Piece

Boltzman constant Apparatus with PN Junction Diode with Aluminum Panel & Digital Panel Meters Digital DC Voltmeter to measure the voltage across the diode. Highly stabilized variable D.C. power supply (0 - 2Volts). Digital milliammeter to measure forward bias current in diode. Silicon Diode mounted inside the cabinet. Temperature controlled oven 70 degree C to heat the diode for different set of readings. Digital temperature indicator to measure temperature directly.

Product Image (MTK-332PC)

PHOTO CELL CHARACTERISTICS APPARATUS

Price: 10 INR/Piece

Photo Cell Characteristics Apparatus Instruments Comprises of DC supply 0-50 V DC Two round meters for voltage and current measurement valve diagram is printed on front panel & light source without bulb.

Product Image (MTK-348PLR)

PN / ZENER DIODE / LED CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS

Price: 10 INR/Piece

PN / Zener Diode / LED Characteristics Apparatus with Bakelite Panel & Round Meters Output voltage (Regulated) : 0-3V/30V DC ( Selectable) Meters (Analog): 65mm round 0-3V/30V DC (Dual Range), 0-100uA / 10mA DC (Dual Range). Housed in PVC cabinet, symbol diagram printed, connections of various components (PN Junction Diode 0A 79, Zener diode 5.1V, LEDs (Red, Green & Yellow), all important outputs & test points brought at Bakelite front panel.

Product Image (MTK-512PR)

H PARAMETERS OF PNP TRANSISTOR IN COMMON EMITTER MODE WITH BAKELITE PANEL & ROUND METERS

Price: 10 INR/Piece

H ParaMeters of PNP Transistor in Common Emitter mode with Bakelite Panel & Round Meters, Objective: Calculation of H Parameters, such as current gain, input impedance, Output impedance and reverse feedback ratio. Features: Instrument comprises of Two DC Regulated Power Supplies 0-10VDC/150mA, 0-1VDC/150mA, Four round meters, One PNP Transistor mounted behind the panel, connections of Supplies, Meters & Transistor brought out at 4mm Sockets

Product Image (MTK-318SR)

SCR CHARACTERISTICS APPARATUS WITH BAKELITE PANEL & ROUND METERS

Price: 10 INR/Piece

SCR Characteristics Apparatus with Bakelite Panel & Round Meters It has an inbuilt variable DC-regulated power supply with an output voltage range of 0-30V DC. The setup includes on-board analog moving coil meters that can measure both voltage and current. The voltmeter has a dual range of 0-1.2V/0-30V, while the ammeter has a dual range of 0-200uA DC and 0-1.2mA/0-30mA.An SCR of 2P4M will be used for the experiment. The entire setup will be enclosed in a lightweight and shock-proof plastic cabinet.

Product Image (MTK-309PP)

ENERGY BAND GAP BY FOUR PROBE METHOD

Price: 10 INR/Piece

Energy Band Gap by Four Probe Method Material: Mild Steel Phase: Single Phase Country of Origin: Made in India

Product Image (MTS-19011A)

DIODE VALVE CHARACTERISTICS APPARATUS WITH TWO ANALOG ROUND METERS

Price: 10 INR/Piece

Diode Valve Characteristics Apparatus with Two Analog Round Meters

Product Image (MTK-315CA)

IGBT CHARACTERISTICS & APPLICATION

Price: 10 INR/Piece

IGBT Characteristics & Application Two variable DC supplies 0 to 12 V & 0 to +/- 15 V @ 500 mA On panel IGBT with circuit diagram Two dual range digital panel meters. Required numbers of patch cords and operating manual.

Product Image (MT-352PM)

IONIZATION POTENTIAL OF MERCURY USING THYRATRON VALVE WITH TWO ANALOG ROUND METERS

Price: 10 INR/Piece

Ionization Potential of Mercury using Thyratron Valve with Two Analog Round Meters

Product Image (MTS-19011B)

TRIODE VALVE CHARACTERISTICS APPARATUS WITH THREE ANALOG ROUND METERS

Price: 10 INR/Piece

Triode Valve Characteristics Apparatus with Three Analog Round Meters

Product Image (MPH-EE-32B)

PLANCKS CONSTANT APPARATUS USING LED

Price: 10 INR/Piece

Plancks Constant Apparatus using LED The setup consists of: Variable Power supply: 0 “ 5 V with precision voltage control facility. Digital Voltmeter: 3 Digit LED Display, 0 “ 20 V. Digital Milli ammeter: 3 Digit LED Display, 0 “ 20 mA. Set of LED fittings on board [ Four nos. colour : Red, Green, Yellow and Orange]

Product Image (MT-329DT)

DIGITAL IC TRAINER

Price: 10 INR/Piece

Digital IC Trainer Features: User friendly front panel. On board useful resources. On board DC Power Supply. On board Logic Level Generator. On board Logic Level Indicator. Diagrammatic representation of circuits for the ease of connections. Power ON switch with indicator. Symbols and Diagrams are printed on Glass Epoxy PCB. All important points are brought out in front panel with 2mm banana sockets. Attractive ABS Plastic Cabinet. Learning™s: Study of 2 /4 input NAND Gate Study of 2/3 input NOR Gate Study of NOT Gate Study of AND Gate Study of 2 Input OR Gate Study of 2 Input EX OR Gate Study of BCD to 7 Segment Decoder IC Study of JK Flip Flop Study of 4Bit Synchronous Binary Counter

Product Image (MPH-EE-32A)

PLANCKS CONSTANT APPARATUS USING PHOTO CELL

Price: 10 INR/Piece

Plancks Constant Apparatus using Photo Cell Display: Digital Size: W 10"x D 8"x H 4" Cord Length: 2m Cord Diameter: 4 mm Weight: 5.5 Kg. (Approx.) Voltage: 220 V Power: 40 W

Product Image (MT-331LT)

LINEAR IC TRAINER

Price: 10 INR/Piece

Linear IC Trainer SCOPE OF LEARNING: Study and Construction of Various Analog IC Experiment SALIENT FEATURES: Front Panel Built With High Class Insulated Printed Circuit Board Sheet With Well Printed Circuits And Symbols. Fuse For Short Circuit Protection Instruction Manual. Connections are brought out through 2mm Brass Sockets. Patch Cords 2mm. The trainer is housed in ABS Plastic cabinet. Size of the trainer set 12x10

Product Image (MTS-19011C)

TETRODE/PENTODE VALVE CHARACTERISTICS APPARATUS WITH FIVE ANALOG ROUND METERS

Price: 10 INR/Piece

Tetrode/Pentode Valve Characteristics Apparatus with Five Analog Round Meters

Product Image (MTK-3016D)

DESOLDERING STATION (WITH AUTOMATIC VACCUME SUCTION DESOLDERING PUMP)

Price: 10 INR/Piece

Desoldering Station (with Automatic Vaccume Suction Desoldering Pump) Power Consumption: 60 Watts I/P Voltage: 170 to 270 V De-soldering: 70 Watt Temperature Range: 180 to 480 Centigrade Power Consumption : 270 Watts Hot Air Temperature : 200 to 550 Centigrade

Product Image (MT-649N)

OSCILLOSCOPE PROBE 20/30MHZ LENGTH 38 INCHES

Price: 10 INR/Piece

Spares Oscilloscope Probe 20/30MHz Length 38 Inches

Product Image (MTK-300PF)

SINGLE PHASE DYNAMOMETER TYPE PORTABLE POWER FACTOR METER

Price: 10 INR/Piece

Single Phase Dynamometer Type Portable Power Factor Meter Select any one range : Current Coil/Potential Coil : 5A/250V OR 5A/500V

Product Image (MTK-301WA)

SINGLE RANGE SINGLE PHASE DYNAMOMETER TYPE PORTABLE WATTMETER (U.P.F TYPE)

Price: 10 INR/Piece

Single Range Single Phase Dynamometer Type Portable Wattmeter (U.P.F Type) Select any one range : Current Coil/Potential Coil :4Ax250V OR 5Ax250V OR 4Ax500V OR 5Ax500V OR 12Ax250V OR 10Ax500V

Product Image (MTK-3016A)

HOT AIR SOLDERING STATION

Price: 10 INR/Piece

Hot Air Soldering Station Material: MS Wattage: 700 watts Input Voltage: 110V Power Consumption: 700W

Product Image (MTK-3016B)

SOLDERING & DESOLDERING STATION (WITH AUTOMATIC VACCUME SUCTION DESOLDERING PUMP)

Price: 10 INR/Piece

Soldering & Desoldering Station (with Automatic Vaccume Suction Desoldering Pump) Power Consumption: 60 Watts I/P Voltage: 170 to 270 V De-soldering: 70 Watt Temperature Range: 180 to 480 Centigrade Power Consumption : 270 Watts Hot Air Temperature : 200 to 550 Centigrade

Product Image (MTK-300PFA)

THREE PHASE,FOUR WIRE DYNAMOMETER TYPE PORTABLE POWER FACTOR METER

Price: 10 INR/Piece

Three Phase,Four Wire Dynamometer Type Portable Power Factor Meter Select any one range : Current Coil/Potential Coil : 2.5A/250V OR 5A/250V OR 10A/110V

Product Image (MTK-302)

SINGLE PHASE DIGITAL PORTABLE TYPE WATTMETER 200 OR 2000 WATTS (LED DISPLAY)

Price: 10 INR/Piece

Single Phase Digital Portable Type Wattmeter 200 or 2000 Watts (LED Display)

Product Image (MTK-741SPA)

4MM TO 4MM SINGLE POINT PATCH CHORD FOR INTER-CONNECTION LENGTH 15 INCHES

Price: 10 INR/Piece

4mm to 4mm Single Point Patch Chord for inter-connection Length 15 Inches

Product Image (MTK-301WB)

DUAL RANGE SINGLE PHASE DYNAMOMETER TYPE PORTABLE WATTMETER (U.P.F TYPE)

Price: 10 INR/Piece

Dual Range Single Phase Dynamometer Type Portable Wattmeter (U.P.F Type) Select any one range : Current Coil/Potential Coil :1/2A x75/150V OR 2.5/5Ax150/300V OR 5/10Ax150/300V

Product Image (MTK-741DPA)

4MM TO 4MM DOUBLE POINT PATCH CHORD FOR INTER-CONNECTION LENGTH 15 INCHES

Price: 10 INR/Piece

4mm to 4mm Double Point Patch Chord for inter-connection Length 15 Inches

Product Image (MTK-302A)

SINGLE PHASE DIGITAL PORTABLE TYPE WATTMETER 2000 WATTS, RESOLUTION - 1WATT (LCD DISPLAY)

Price: 10 INR/Piece

Single Phase Digital Portable Type Wattmeter 2000 Watts, Resolution - 1Watt (LCD Display)

Product Image (MTK-303VF)

TRIPPLE RANGE MOVING COIL DC PORTABLE VOLTMETER

Price: 10 INR/Piece

Tripple Range Moving Coil DC Portable Voltmeter Select any one range : 0-50/100/200V OR 75/150/300V OR 150/300/600V

Product Image (MTK-736AA)

BNC TO BNC CRO PROBE LENGTH 34 INCHES

Price: 10 INR/Piece

BNC to BNC CRO Probe Length 34 Inches

Product Image (MTK-741SPB)

2MM TO 2MM SINGLE POINT PATCH CHORD FOR INTER-CONNECTION LENGTH 15 INCHES

Price: 10 INR/Piece

2mm to 2mm Single Point Patch Chord for inter-connection Length 15 Inches

Product Image (MTK-301WD)

TWO CURRENT AND THREE VOLTAGE RANGE SINGLE PHASE DYNAMOMETER TYPE PORTABLE WATTMETER (L.P.F TYPE)

Price: 10 INR/Piece

Two Current and Three Voltage Range Single Phase Dynamometer Type Portable Wattmeter (L.P.F type) Select any one range: Current Coil/Potential Coil: 1/2A x75/150/300V OR 2.5/5Ax 150/ 300/ 600V OR 5/10Ax150/300/600V

Product Image (MTK-310AC)

ANALOG COMPONENT TRAINER

Price: 10 INR/Piece

Analog / Descrete Component Trainer Trainer comprises Power supplies inside the trainer Power supplies on boards 0-50 V, 250 mA and 0-30 V, 250 mA Variable 15 V/150 mA and 5 V/150 mA Fixed Supplies provided 4 Nos of Variable resistor provided on the board One 20 Pin Veroboard on mounted on the board Ac power supply 15-0-15 V for rectifier applications 2 Nos. of digital meters provided on board Various components on the trainer set 3 Pairs of connected 2 mm sockets 4 Rectifier diodes 1 OA79 germanium diode 3 different values of Zener N different values resistances N different values capacitors

Product Image (MTK-304AA)

SINGLE RANGE MOVING IRON AC/DC PORTABLE AMMETER

Price: 10 INR/Piece

Single Range Moving Iron AC/DC Portable Ammeter Select any one range : 0-5A OR 10A OR 15A OR 30A OR 50A

Product Image (MTK-741DPB)

2MM TO 2MM DOUBLE POINT PATCH CHORD FOR INTER-CONNECTION LENGTH 15 INCHES

Price: 10 INR/Piece

2mm to 2mm Double Point Patch Chord for inter-connection Length 15 Inches

Product Image (MTK-3016)

DIGITAL ANTISTATIC SOLDERING STATION

Price: 10 INR/Piece

Digital Antistatic Soldering Station Adjustable temperature and a variety of available tips. Grounded tip for soldering static sensitive devices. Overheat protection with closed loop temperature control. Improved circuit design for greater temperature stability. Heat resistant soldering iron cord. Built-in tray with cleaning sponge. Specifications of Soldering Station with Digital Display Power Consumption: 48 W Temperature: 160 - 420 DEGREE C Voltage: 220 - 240 VAC/50 Hz Included with 3 pcs replacement tips

Product Image (MTK-304AB)

SINGLE RANGE MOVING COIL DC PORTABLE AMMETER

Price: 10 INR/Piece

Single Range Moving Coil DC Portable Ammeter Select any one range : 0-1A OR 3A OR 5A OR 10A OR 15A OR 30A OR 50A

Product Image (MTK-735BNB)

BNC TO CROCODILE CRO PROBE LENGTH 36 INCHES

Price: 10 INR/Piece

BNC to Crocodile CRO probe Length 36 Inches

Product Image (MTK-304AC)

DUAL RANGE MOVING IRON AC/DC PORTABLE AMMETER

Price: 10 INR/Piece

Dual Range Moving Iron AC/DC Portable Ammeter Select any one range : 0-1/2A OR 2.5/5A OR 5/10A OR 10/20A OR 15/30A OR 30/60A

Product Image (MTK-304AD)

DUAL RANGE MOVING COIL DC PORTABLE AMMETER

Price: 10 INR/Piece

Dual Range Moving Coil DC Portable Ammeter Select any one range : 0-1/2A OR 2.5/5A OR 5/10A OR 10/20A OR 15/30A OR 30/60A

Product Image (MTK-3016C)

SOLDERING STATION MAINTENANCE CENTER

Price: 10 INR/Piece

Soldering Station Maintenance Center Power Consumption: 48 W Temperature: 160 - 420 DEGREE C Voltage: 220 - 240 VAC/50 Hz Included with 3 pcs replacement tips

Product Image (MTK-301WE)

THREE PHASE,FOUR WIRE DYNAMOMETER TYPE PORTABLE WATTMETER (U.P.F TYPE)

Price: 10 INR/Piece

Three Phase,Four Wire Dynamometer Type Portable Wattmeter (U.P.F Type) Select any one range : Current Coil/Potential Coil :1/2A x110V OR 2.5/5Ax125V OR 5/10Ax150V OR 2.5/5Ax440V

Product Image (MTK-301WC)

TWO CURRENT AND THREE VOLTAGE RANGE SINGLE PHASE DYNAMOMETER TYPE PORTABLE WATTMETER (U.P.F TYPE)

Price: 10 INR/Piece

Two Current and Three Voltage Range Single Phase Dynamometer Type Portable Wattmeter (U.P.F type) Select any one range : Current Coil/Potential Coil :1/2A x75/150/300V OR 2.5/5Ax150/300/600V OR 5/10Ax150/300/600V

Product Image (MTK-310DC)

DESCRETE COMPONENT TRAINER

Price: 10 INR/Piece

Analog / Descrete Component Trainer Power supplies on boards 0-50V, 250 mA and 0-30V,250mA Variable 15V/150mA and 5V/150mA Fixed Supplies provided on board. 4 Nos of Variable resistor provided on the board. One 20 Pin Vero board on mounted on the board. Ac power supply 15-0-15V for rectifier applications

Product Image (MTK-303VC)

DUAL RANGE MOVING IRON AC/DC PORTABLE VOLTMETER

Price: 10 INR/Piece

Dual Range Moving Iron AC/DC Portable Voltmeter Select any one range : 0-5/10V OR 10/20V OR 15/30V OR 75/150V OR 150/300V OR 300/600V

Product Image (MTK-303VA)

SINGLE RANGE MOVING IRON AC/DC PORTABLE VOLTMETER

Price: 10 INR/Piece

Portable Voltmeters/Ammeters / P.F Meters/Wattmeters Single Range Moving Iron AC/DC Portable Voltmeter Select any one range : 0-10V OR 15V OR 20V OR 25V OR 30V OR 50V OR 100V OR 150V OR 300V OR 600V

Product Image (MT-802MC)

DC MICRO AMMETER 0-250A OR 0- 300A

Price: 10 INR/Piece

DC MICRO AMMETER 0-250µA OR 0- 300µA

Product Image (MPH-EE-72)

DC AMMETERS ( 0-1,2,5,...10 AMPS (INTERNAL SHUNT)

Price: 10 INR/Piece

PORTABLE & MOVING COIL DESK TOP METER Analog Moving Coil Meters DC Ammeters ( 0-1,2,5,...10 Amps (Internal shunt)(Select Any One Range) A multi-range rectangular ammeter mounted on top of a sturdy plastic box, providing multiple ranges selectable through a rotatory knob with AC/DC selection through a toggle switch. AC output available through a pair of 4mm yellow shielded sockets and DC output through a pair of 4mm colour-coded shielded sockets.

Product Image (MTK-303VB)

SINGLE RANGE MOVING COIL DC PORTABLE VOLTMETER

Price: 10 INR/Piece

Single Range Moving Coil DC Portable Voltmeter Select any one range : 0-1V OR 3V OR 5V OR 10V OR 15V OR 30V OR 50V OR 100V OR 150V OR 300V OR 600V

Product Image (MT-804RAT)

AC AMMETER (RECTIFIER TYPE) 0-1,3,5. 10A (WITH CURRENT TRANSFORMER)

Price: 10 INR/Piece

AC AMMETER (RECTIFIER TYPE) 0-1,3,5. 10A (WITH CURRENT TRANSFORMER)

Product Image (MT-802MM)

DC MILLI AMMETER 0-1,3,5,10,15,25,30,...1000MA

Price: 10 INR/Piece

DC Milli Ammeter 0-1,3,5,10,15,25,30,...1000mA (Select Any One Range) Features: Exact measurement Compact design Light in weight Product Description: It is much helpful in conrming the polarity of instrument Transformers. It is most widely used in Erection activities for instrument Transformers.

Product Image (MTK-303VD)

DUAL RANGE MOVING COIL DC PORTABLE VOLTMETER

Price: 10 INR/Piece

Dual Range Moving Coil DC Portable Voltmeter Select any one range : 0-5/10V OR 10/20V OR 15/30V OR 75/150V OR 150/300V OR 300/600V

Product Image (MT-804RBT)

AC MILLI AMMETER (RECTIFIER TYPE) 0-1,10, 30,100,300 ..1000MA (WITHOUT CURRENT TRANSFORMER)

Price: 10 INR/Piece

AC Milli Ammeter (Rectifier Type) 0-1,10, 30,100,300 ..1000mA (Without current transformer) (Select Any One Range)

Product Image (MT-802MD)

DC MICRO AMMETER 0-500A

Price: 10 INR/Piece

DC MICRO AMMETER 0-500µA

Product Image (MPH-EE-74)

GALVANOMETER 30-0-30 DIVISION SENSITIVITY OF 20A/DIVISION

Price: 10 INR/Piece

Galvanometers Galvanometer 30-0-30 Division Sensitivity of 20µA/Division

Product Image (MPH-EE-75)

DC VOLTMETER 0-1,3.5.10,15,30..600V

Price: 10 INR/Piece

DC VOLTMETER 0-1,3.5.10,15,30..600V

Product Image (MPH-EE-74A)

GALVALNOMETER 30-0-30 DIVISION SENSITIVITY OF 2A/DIVISION

Price: 10 INR/Piece

Galvalnometer 30-0-30 Division Sensitivity of 2µA/Division

Product Image (MTK-303VE)

TRIPPLE RANGE MOVING IRON AC/DC PORTABLE VOLTMETER

Price: 10 INR/Piece

Tripple Range Moving Iron AC/DC Portable Voltmeter Select any one range : 0-50/100/200V OR 75/150/300V OR 150/300/600V

Product Image (MT-804M)

MILLI VOLTMETER DC 0-60MV

Price: 10 INR/Piece

Milli Voltmeter DC 0-60mV

Product Image (MT-802MA)

DC MICRO AMMETER 0-50A

Price: 10 INR/Piece

DC Micro Ammeter 0-50µA Case: Clear Transparent Front Cover Desk Stand: Front Terminal unbreakable ABS plastic Black Desk Stand Scale Length: 60mm (approx.)

Product Image (MT-804RT)

AC VOLTMETER (RECTIFIER TYPE) 0-1,3,5,10..30V

Price: 10 INR/Piece

AC VOLTMETER (RECTIFIER TYPE) 0-1,3,5,10..30V

Product Image (MT-802MB)

DC MICRO AMMETER 0-100A

Price: 10 INR/Piece

DC MICRO AMMETER 0-100µA

Product Image (MT-804RTA)

AC VOLTMETER (RECTIFIER TYPE) 0-50,100,150, 600V

Price: 10 INR/Piece

AC VOLTMETER (RECTIFIER TYPE) 0-50,100,150, 600V

Product Image (MTIT-25)

DIGITAL INSULATION TESTER

Price: 100 INR/Piece

Digital Insulation Tester For testing insulation 250v-500V,50Hz EARTH: Connected to the shell of DUT or on the ground. GUARD: Connected to HV retaining ring of DUT in order to eliminate the effection of surface leakage current. LINE; High-voltage output terminal, connected to high-voltage conductor of DUT. LCD Display : Display test results and setting parameters INDICATOR: Showing HV output, power supply working, charging TEST KEY: Press Start testing, clockwise rotation can be locked after pressing the button CHARGING JACK: 15-19V DC SHIFT: Selecting Output voltage, also power switch

Product Image (MTS-850HM)

DC LOW OHM METER

Price: 100 INR/Piece

DC Low Ohm Meter Display: 4 Digit. Backlight LCD Display User friendly operation Auto Ranging Four Wire Measurement Percentage error selectable in three steps. Alarm indication. Multi-display of Parameters

Product Image (MTS-673SA)

SWEEP SIGNAL ANALYZER

Price: 100 INR/Piece

Sweep Signal Analyzer Frequency range: 1300MHz Output voltage: 0.5Vrms/75ohms Output flatness: Better than ±0.15dB Output attenuator: 10dB in 7 steps and 1 dB in 10 steps Marker display: 50MHz, 10MHz, 1 MHz and external Frequency Vertical deflection factor: Better than 2mVp-p/div

Product Image (MTS-370DT)

DIGITAL TRANSISTOR TESTER

Price: 100 INR/Piece

Digital Transistor Tester Measuring forward voltage, reverse voltage, forward saturation voltage drop, amplification factor, reverse leakage current of various crystal diode, audios, silicon controlled rectifier (SCR), field effect transistor (FET) Measuring protection voltage of varistor Measuring starting voltage of neon bulb, neon lamp Measuring constant voltage value of 78,79 series three-pole circuit Standard Accessories: Hard case (Meter Enclosed), Test Leads, Manual Dimension: 150 (H) x 100 (W) 70 (D)mm 3 Digit LCD Display, 2000 Counts, Data Hold Function, Auto Range

Product Image (MT-898M)

STROBOSCOPE (50~40000FPM)

Price: 100 INR/Piece

Stroboscope (5040000FPM) Measurement Range: A : 50 40,000 FPM Accuracy: +/-(0.05%n + 1d) Resolution: 0.1FPM(50 999.9 FPM) 1 FPM(Over 1000FPM) Sampling time: 0.3 sec Internal/External Triggering conversion External Trigger level: 3 24V With x2, /2 for fast check

Product Image (MTER-25)

DIGITAL EARTH TESTER

Price: 100 INR/Piece

Digital Earth Tester 3-wire earth electrode resistance tester. Simple one button operation. For earth testing of electrical installations, complete with earthling rods connection clamp, 30m cable and all standard accessories.

Product Image (MTS-859DM)

DISTORTION METER 20HZ~20KHZ

Price: 100 INR/Piece

Distortion Meter 20Hz20kHz Auto range and distortion measurement Auto or hold function selectable 7 distortion ranges: 1% - 100% Frequency: 20Hz20KHz continuously adjustable in 3 ranges 3 spot frequency: 400Hz, 1KHz, 10KHz 12 AC voltage range: 1mVrms 300Vrms

Product Image (MT-101220)

TACHOMETER 2 IN 1(CONTACT TYPE 0.5~19,999RPM & PHOTO TYPE 5~99,999RPM)

Price: 100 INR/Piece

Tachometer 2 in 1(Contact Type 0.519,999RPM & Photo Type 599,999RPM)

Product Image (MTRM-22)

Rlcv Meter (Digital)

Price: 10 INR/Piece

RLCV METER (DIGITAL) Features: LCD digital display Wide dynamic range Data hold function Low power indication Auto power off Overload protection Specification: Parameter measure.4c/Raccuracy+0.7% Resistance=10m-10M Inductance=10mf"1000p4 Power supply-9vdc Power adaptor (external) Dc 12V min"15v max 50mA With all accessories and operation manual

Product Image (MTLP-22)

LOGIC PROBE

Price: 5 INR/Piece

LOGIC PROBE This logic probe provides convenient and precise measurement of logic circuits. High intensity LED readouts provide instant response to the logic state. Tests all logic families (ttl lsi CMOS ect)

Product Image (MTEP-12)

Electro-pneumatic System Teaching Model

Price: 1000 INR/Piece

Electro-pneumatic System Teaching Model Suitable for introducing basic principle of electro-pneumatic control consisting of fixing board, Electro pneumatic valves, actuating switches and all accessories

Product Image (MTIT-25)

Portable Insulation Tester

Price: 10 INR/Piece

Portable Insulation Tester For testing insulation 250v-500V,50Hz EARTH: Connected to the shell of DUT or on the ground. GUARD: Connected to HV retaining ring of DUT in order to eliminate the effection of surface leakage current. LINE; High-voltage output terminal, connected to high-voltage conductor of DUT. LCD Display : Display test results and setting parameters INDICATOR: Showing HV output, power supply working, charging TEST KEY: Press Start testing, clockwise rotation can be locked after pressing the button CHARGING JACK: 15-19V DC SHIFT: Selecting Output voltage, also power switch

Product Image (MTCM-22)

Three-phase Pole Changing Motor

Price: 100 INR/Piece

Three-phase Pole Changing Motor Open drip proof enclosure 1-2 hp for 220/380v, 50HZ 1500/3000 rpm. Separate winding

Product Image (MTPI-56)

Phase Sequence Indicator

Price: 10 INR/Piece

Phase Sequence Indicator Range:hp -1hp Voltage:230 Volt AC Frequency:25- 60 Hz Power Source:Electric Working Temperature:0to50 DegreeC Phase Type: Three Phase

Product Image (MTPP-40)

Compact Plc With Programmer

Price: 10 INR/Piece

Compact Plc With Programmer Programmable logic controller used to operate different Pneumatic control system with all accessories soft ware. Portable training system integrates an panel, networking, and a variety of programming commands in order to simulate processes. In addition to a discrete I/O simulator with discrete switches and indicators, the system includes application circuits and components for thermostatic temperature control, and variable speed motor control.

Product Image (MTLC-10)

LOGIC CLIP

Price: 5 INR/Piece

LOGIC CLIP High Precision Connector Pin Logic Analyzer IC test clips, simplify Dip testing in proto types, quality control, and production. Nail head style test pins Type: 8 -pin Test clip 14-pin Test clip 10-pin Test clip 64-pin Test clip

Product Image (MTST-22)

Single Phase Transformer

Price: 10 INR/Piece

Single Phase Transformer Shell type Power132VA Voltage220/55V400/100

Product Image (MTCP-22)

Digital Clamp On Tester/Meter

Price: 10 INR/Piece

Digital Clamp On Tester/Meter DC voltage 1000V, AC 600 V, AC current 200-600A NO buzzer off and diode test function. Power:2x1.5VAAA (Not Included) Product type:Multimeters 3 1/2 digits LCD, with a max. reading of 1999 DC Voltage:600V,(0.8%+3dgt) Resistance:2K-200K-2M,(1.0%+3dgt) Fire wire test function Material:Plastic, Electronic Parts Max display:1999

Product Image (MTLT-29)

LOGIC TRACER

Price: 5 INR/Piece

LOGIC TRACER Rapid visual pulse and logic level indicator, compatible with TTL, DTL, and most other IC logic and protected against extreme overload with input impedance: 10k Trigger threshold+1.4V,nominal Minimum pulse width25ns Overload production Including accessories, BNC to alligator clips, BNC to banana plug adapter, BNC connector, ground cable assembly, operation manual

Product Image (MTMG-26)

MANIFOLD GAUGE ASSEMBLY

Price: 10 INR/Piece

MANIFOLD GAUGE ASSEMBLY Standard 1 meter hose with knurled hard connections. Colored for each of identification red for high pressure, blue for low pressure, yellow for charging. High Pressure or Low Pressure is Selectable Pressure in PSI Extra Large Easy to Read Color Coded Dials Rubber gauge covers for added protection Durable Metal Casing Aluminum Alloy Testing Manifold Body High Impact Pop-in Lexan Lens A heavy Duty Hook for Hanging the Gauges Brass Connection

Product Image (MTFT-22)

Fm Transmitter Trainer

Price: 10 INR/Piece

Fm Transmitter Trainer Transmitter frequency:88 to 108 MHZ range output RF, power:100mW Source:+15V stabilized Consumption:300mA (worst case) With all necessary accessories operation manual and schematic diagrams

Product Image (MTPC-40)

TRAINING MODEL OF (PNEUMATIC CONTROLLER)

Price: 1000 INR/Piece

TRAINING MODEL OF (PNEUMATIC CONTROLLER) Suitable for introducing basic principle of pneumatic, basic principle in control mechanism with all accessories.Consists of air delivery compressor, operate at 220v-1-diamter single acting cylinder flow control valve, time delay valve of different type of valve actuators Design and function of an Electro Pneumatic system “ Basic Function and identification of Electro-pneumatic components and their symbols Direct and indirect manual controls, stroke dependant controls, time dependant controls. Functional diagrams Systematic design of Electro Pneumatic Sequence Controls

Product Image (MTAC-25)

Trainer Model Air Conditioner

Price: 1000 INR/Piece

Trainer Model Air Conditioner Specification: System capacity: 0.5 1TR Hermetic Compressor:0.5 1 kW Refrigerant: R134 Fan coil air flow rate:250 M3/hr approx. Main Structure: Base stand. Air conditioner consists of: Hermetically sealed Compressor Air cooled Condenser:Fin & Tube type, Forced Drought Expansion device(capillary & thermstatic expansion valve) Evaporator Pre-heater Control room (Chamber)of size 39X32X32 having two separates ducts for suction of Fresh air and discharge of conditioned air. Instruments in control chamber: Electrical Air heater Wet and dry bulb thermometer. Control Panel consisting of following Instruments/Items: Temperature indicator Pt 100 sensor (penciltype & bulb type.) Ammeter Voltmeter (Drier & filter Refrigerant Mains switch Compressor ON/OFF D.P.switch Heater dimmer H.P LP cut out Pressure gauge Rotameter Servicesrequired at site: Single phase supplywith proper earthing

Product Image (MTCT-55)

Capacitor Tester

Price: 10 INR/Piece

Capacitor Tester Equivalent to DB230 Capacitor Tester Capacitance Range:200pF - 200mF Accuracy:+/-0.5%+1 to+/- 5%+10 Sampling time 3 per second

Product Image (MTER-25)

Portable Earth Resistance Meter

Price: 10 INR/Piece

Portable Earth Resistance Meter 3-wire earth electrode resistance tester. Simple one button operation. For earth testing of electrical installations, complete with earthling rods connection clamp, 30m cable and all standard accessories.

Product Image (MTSM-20)

Three- Phase Squirrel Cage Motor

Price: 100 INR/Piece

Three- Phase Squirrel Cage Motor Open drip proof enclosure 1-2 hp for220/380v,50HZ 1500/3000rpm Separate winding

Product Image (MT-599)

Zener Diode

Price: 5 INR/Piece

Zener Diode Current (Amp):2-5 Output Voltage (V):12 V Impedance:Max. 7 Ohm Tolerance:+/- 5% Operating Temperature:-65 to 200 Degree Celsius

Product Image (MT-603)

Amplifier/Multiplexer Board

Price: 5 INR/Piece

Amplifier/Multiplexer Board Multiplexes 16 differential inputs to one A/D input analog inputs to 128 channels High-grade amplifier provides switch selectable gains of 1,2,10,50,100,200,1000 Onboard cold-junction compensation circuits for direct thermocouple measurement Built-in signal conditioning functions include filter, attenuator and current shunt Second connectors onboard allow daisy chaining Screw-clamp terminal blocks permit easy and reliable connections

Product Image (MT-508)

Bluetooth Module Hc-05

Price: 5 INR/Unit

Bluetooth Module Hc-05 Sales Package:Hc-05 Bluetooth Module With Base Skill set:Sensory Development Number Of Batteries:0 Batteries Minimum Age:10 years Battery Operated: No Battery Type:No batteries Rechargeable: No

Product Image (MT-501)

Microcontroller 8051/2 Development Kit

Price: 3 INR/Unit

Microcontroller 8051/2 Development Kit

Product Image (MT-503)

Arm Cortex M4 Evaluation/Development Boards

Price: 4 INR/Unit

Arm Cortex M4 Evaluation/Development Boards Integrates various standard interfaces 2 x Audio In 2 x User keys pretty easy for peripheral expansions

Product Image (MT-813)

AC/DC CONVERSION TRAINER

Price: 10 INR/Unit

AC/DC CONVERSION TRAINER Line In Voltage:100-277VAC @4763 Hz Line Out:12VDC @11 Amps Watts:106 AC Input Connector:1Pigtail,Straight Blade Plug DC Output Connector:1Pigtail,Cigarette Plug Socket Protection:Short Circuit/Overload/ Over Voltage Mounting:Two Screw Slide Notches Operating Temp:-20/+60C Efficiency:85%

Product Image (MT-815)

Dc/ac Conversion Trainer

Price: 5 INR/Unit

Dc/ac Conversion Trainer Voltage:230 V AC Capacity:80 AH Battery:12 V Power:40 W

Product Image (MT-811)

Thyristor Trainer

Price: 5 INR/Unit

Thyristor Trainer On board DC Regulated Power Supply 5 V at 250 MA On board Square Wave Generator On Board RL and RC Circuit Provided With Circuit Diagram Components are mounted behind the panel Adequate no. Of patch cords stackable from rear both ends 4 mm spring loaded plug length meter Good quality, reliable terminal/sockets are provided at appropriate places on panel for connections/ observation of waveforms Trainer is housed in highly shockproof plastic box having size of 12 x 8 inches

Product Image (MT-507)

Arduino Nano Starter Kit

Price: 100 INR/Unit

Arduino Nano Starter Kit 1*Box 1*830 Holes breadboard 1*Nano expansion board 1*Funduino Nano expansion board 1*LCD(1602) 1*40 pin header 1*USB cable 1*4-digit tube 1*1-digit tube 1*Active buzzer 1*Passive buzzer 1*Matrix module(8*8) 1*Remote controller(white) 1*RGB patch 1*Relay module(5V) 1*Battery case(6*AA) 1*74HC59M chip 4*Female to female cable 30*Breadboard jumper wires 5*1K Resistors 5*10K Resistors 8*220R Resistors 4*Small buttons 1*Receiver 1*LM35 Temperature sensor 3*Photoresistors 2*Roll ball 1*Flame sensor 1*50KOhm Adjustable potentiometer

Product Image (MT-502)

Pic 16/32 Development Board With Usb Programmer

Price: 5 INR/Unit

Pic 16/32 Development Board With Usb Programmer

Product Image (MT-504)

Microcontroller Development Kit for Arduino

Price: 5 INR/Unit

Microcontroller Development Kit for Arduino

Product Image (MT-506)

Arduino Nano

Price: 5 INR/Unit

Arduino Nano Microcontroller:ATmega328 Architecture:AVR Operating Voltage:5 V Flash Memory:32 KB of which 2 KB used by boot loader SRAM:2 KB Clock Speed :16 MHz Analog IN Pins:8 EEPROM:1 KB DC Current per I/O Pins:40 MA (I/O Pins) Input Voltage:7-12 V Digital I/O Pins:22 (6 of which are PWM) PWM Output:6 Power Consumption:19 MA PCB Size :18 x 45 mm Weight:7

Product Image (MTS-880)

Modular Power Hub

Price: 100 INR/Piece

Modular Power Hub We are manufacturers of finest Modular Power Hub in India and also supplies and exporters Modular Power Hub around the world at best prices. To enquiry Modular Power Hub , please fill below form. Will be back with you Feature : DC power cord application eliminates the use of the extension cord keeping your server room neat Front panel LEDs indicate the real-time power consumption Fool-Proof plugs, avoid short-circuitry Provide 8 extra power source for the connected devices 4 DC receptacles on the front panel plus 4 DC receptacles on the rear panel make connections easy to reach

Product Image (MTS-865)

Transformer Trainer

Price: 10 INR/Piece

"TEKNIK" Transformer Trainer : MTS-865 Transformer Trainer demonstrates the principles of Lenzs first and second laws as applied to transformers. Typical material covered includes efficiency, ratios, vectors, open circuit test and short circuit test. Specifications:S1 x Single Phase Current. 1 x Three Phase Current. 1 x three phase voltage and current. Low voltage power supplies: 0-30V DC and 0-30V AC. Transformers: 2 x Low voltage single phase 150VA (one Step Up 30/240V and Other Step Down 240/30V. 1x line power 5KVA three phase star delta Dy11-reduces the incoming supply down. 1 x line receive 3KVA three phase star-delta Dy11with star point link to earth 220V/110V three phase. Includes tap section on its primary windings of +10%, +7.5% , +5%, +2.5%, and 0%. 220V Star connected Resistive, Inductive and capacitive. 110V Delta connected Resistive.

Product Image (MTS-855)

Distribution Transformer Trainer

Price: 100 INR/Piece

Technical Specifications Distribution Transformer Trainer OC SC TEST FOR THREE PHASE TRANSFORMER WITH PANNEL AND TRANSFORMER WITH DIGITAL PANEL METER DISPLAY. The Distribution Transformer Trainer, Model 885, is a portable, hands-on trainer designed to allow students to develop competence in completing single/three-phase transformer connections similar to those performed in the North American power distribution system. The trainer contains two sets of three single-phase transformers to demonstrate three-phase banking configurations, such as wye-wye, delta-delta, closed delta-wye, closed wye-delta, open-wye, open-delta, and others. Each individual transformer winding is protected by a thermally-activated circuit breaker and designed to accept multiple faults. The trainer is faul table in order to develop sound techniques for troubleshooting single-phase and three phase transformer banks. Eight (8) trainer faults are available. The trainer is complete with a student laboratory manual written in a skill-building, performance-based format, allowing easy set-up of all laboratory exercises.

Product Image (MTS-860)

Distribution Trainer

Price: 100 INR/Unit

"TEKNIK" Distribution Trainer : MTS-860 Our vast range of products comprises Distribution Trainer. These are premium quality electrical equipments which facilitate ease of installation and maintenance. These equipments are highly demanded by electrical and electronic industries for varied purposes. These facilitate ease of installation and maintenance. These equipments are suitably tested by experienced auditors prior to dispatch and are supplied to clients at highly economical prices. SPECIFICATION: POWER SUPPLIES: AC SECTION 1.Three phase main power supply siemens rated Value current rating (18A-24A) with protection. Indication light. Emergency OFF Push Switch. Power requirement 380V/50 Hz. 2.Three phase main power supply siemens rated current rating (2.4A-4A) with protection. Indication light. Power requirement 380V/50 Hz. Fixed in front panel. Features of Distribution Trainer Quality tested Sturdy design Damage-resistant

Product Image (MTS-805)

Antenna Trainer Kit

Price: 10 INR/Piece

Antenna Trainer Kit : MTS-805 Antenna Trainer has been designed to provide useful tools for hands on experimentation and teaching of various commonly used antennas in VHF-UHF-Microwave band in the laboratory for students of all levels. It can be used in stand-alone mode as well as be interfaced with a computer via RS-232 interface. In this Receiving antenna is rotated manually from 0 to 360 degrees and accordingly receiving antennas signal strength can be monitored on the Receiver. The system consists of a set of two tripods one for mounting the transmitting antenna and another for mounting the receiving antenna, 22 Antennas, RF Transmitter/ Receiver, Antenna Plotting Software and relevant accessories/ cables. Features: - 2 mobiles and 2 base station units. - 10 types of mobile antennas. - PLL synthesized base station and remote units. - Full duplex voice & data communication link. - Propagation environment experiment. - Automatic retry mode. - Successful or failed data packet acknowledgment.

Product Image (MTS-856)

Electrical Educational Distribution Trainer

Price: 100 INR/Piece

Electrical Educational Distribution Trainer on Stand : MTS-856 Technical specification Fundamental configurable distribution system for ring main or radial feeders with six tapping from either system or the facility to demonstrate the effect of varying the conductor cross section. AC and DC methods are available and two dual wound transformers included for AC demonstration. Both AC and DC variable power supplies range from 0 to 30 volts and the two transformers having 240V windings. 0-300v moving iron voltmeters. 2 nos 0-30v rectified moving coil voltmeters. 3 nos 0-10v rectified moving coil voltmeters. 1 nos 0-1A rectified moving coil voltmeter. 11 nos Indication lamps to indicate volt drop in transmission line. Three phase distribution consists of a three phase neutral distribution line with characteristics. inductive and resistive features. Each phase line is represented by two separate. sets of R and XL, and the neutral is to be divided in the same way. Each phase is to have a current transformer with the secondary taken to the terminals with protective relay. Three single pole protection relays of HV switch gear industry standard are to be included.

Product Image (MTS-850)

Study of Differential Current Relay

Price: 10 INR/Piece

"TEKNIK" Study of Differential Current Relay : MTS-850 The Current Differential/ Over current Relay provides protection for any two-input apparatus such as transformers, motors, generators, and reactors. Apply it for differential and over current protection and use event reports for quick post-event analysis... Two-Winding Current Differential Protection Sensitive current differential protection with programmable single- or dual-slope percentage restraint, supervised by the second- and fifth-harmonic elements for secure differential protection on two-winding apparatus. Choose from common or independent harmonic blocking or restraint. Unrestrained differential elements provide fast operation for high-magnitude internal faults. Automatic calculations of relay tap settings simplify application. Individual Winding Over current Protection Individual winding phase, residual, and negative-sequence over current elements, including instantaneous, definite-time, and inverse Time-over current elements for comprehensive over current protection.

Product Image (MTS-807 )

Telephone Trainer Kit

Price: 100 INR/Piece

Line in section : One dot line connection port Handset : One handset connection port Keyboard : 4x3 matrix keyboard Dialer : Tone and pulse Facilities : Redial up to 32 digits, Mute, Redial, Flash, Pause switches Indicators : Line in, Hook, tone and ringer, Call mute section Control : Ringer volume control, Ringer speed control Speech path : Fully Non-Blocking Dial pulse ratio : 10 pps + / - 10% Tone frequency : 430 Hz Input power : From telephone line

Product Image (MTS-875)

Transmission Line Stimulator

Price: 10 INR/Piece

TEKNIK Transmission Line Stimulator : MTS-875 Transmission line simulator with protection system consists of a miniature transmission line arranged to represent 3 phase AC long transmission line having ACSR conductors 37/0.146 with spacing 6.7 meters to transmit the power of 90 MW at 0.9 p.f. The panel consists of t he following: Auto Transformer (01 nos): Single phase. Input: 230 V, 50 Hz Output: 230 V, 15 Amp Single Phase Transformer (St non): 1 KVA, 110V /220 V, 50 Hz. with equivalent Xe = 0.04 Henry at Sending End. Single Phase Transformer (01 nos): 1 KVA, 220V /220 V with equivalent Xe = 0.44 Henry at Receiving End. Both transformers erect good regulation quality. Single Phase Inductive Load: 220V, 5A arranged R & L with C in parallel (01 Non) to operated at 0.9 lag P.F. Transmission Line: Arranged in 3 phases separately to represent a line, 80 km to 400 km long with R, L and C divided in 5 sections with short circuiting switch or solid plug key for each section. Complete system with auto transformers. ON/OFF contractors, voltmeters, ammeters & watt meter along wIth load to be arranged on panel to study the performance of T.L. for one phase under various conditions. The send ng end voltage on the simulator is 220 V 50 Hz single phase so that if full load transmission is 100 MVA, that of the equivalent musculature system will be 0.872 KVA. Variable Speed Drive (Cl non) To be used as ON/OFF restricting phenomena when T.L is to be investigated for OVER VOLTAGES DUE TO RESTRIKING. Graded Over Current Protect on: By using STATIC/INDUCTION TYPE OVER CURRENT RELAY mounted on panel with terminals of T.L. brought out for connections and arranging graded over current protect on with three static relays in three sections. Protect an by Impedance Fault Simulation Arranged by Induction Type/Static Type Relay by Time Relay dividing the complete T.L in three sections. Suitable tap points are provided with fault creating ON / OFF Switches for study of protection schemes arranged as above one at a time. All the above components are mounted In a panel type enclosure for proper education/training use. The panel provided is ergonomically designed & fabricated using high quality MS sheets of proper gauges duly powder coated for better environmental protection. The components and material used are of industrial grade and good quality for rugged use of the equipment.

X


Back to top
