Laminar Flow Cabinet Digital

Product Description

Micro-Controller based : Menu Controlled with LCD Display. Operation Laminar Airflow Velocity : Average of 0.45 m/s or 90 fpm measured 150mm/6 filter face for 45 air changes/min. in work zone.
Re-circulation : 70% of total.
Air Velocity Exhaust : 30% of total Air Velocity.
Air Cleanliness in Working Area : meets or exceeds US Federal
Standard 209E Class 100.
Main & Exhaust Filters : HEPA (Minipleat Optional).
HEPA Filters : Rated for min. 99.97% efficiency at 0.3 micron particle size.
Pre-Filters : Low pressure drop. High efficiency, 10 microns.
UV Sterilization : In work chamber & Exhaust Plenum.
Emission in the germicidal band UV-Cm 254mm.
Alarm : Door unsafe position.
Noise Level : <58 dbA at operator point.
Power : 220-240V AC / 50 Hz 1 Ph.
Inter Lock : UV / Fluorescent / Door.
Exhaust : Double protection with HEPA & UV.
Motors / Blowers : Double shaft, Balanced, low vibration.
