ELECTRO PNEUMATIC TRAINER

Product Description

The components are capable ofbeing mounted on an appropriate profile plate with grooves for secure andflexible positioning so that the components can be clamped firmly, quickly andsafely through quick fix adaptors.

Industrial components are used inthe kit so that the students get hands on practical training in usingindustrial components.

Advanced customizedelectro-pneumatic trainer kit is capable of being used to demonstrate thedesign, construction and application of electro-pneumatic components andcircuits.

The Kit is designed to satisfy followingobjectives:

Direct and indirect manualcontrols, stroke dependent controls, time dependent and pressure dependentcontrols with time delay, pressure sequence valves.

Design & function of anelectro-pneumatic System.

Function & identification ofElectro-pneumatic components & their symbols.

Functional diagrams.

Logic AND/OR function to startsignals.

To empower students to designtheir own circuits.

The kit is modular andupgradeable.
